Technical Specifications
Expanded and source-backed technical fields for the 5HHL-35.
| Parameter | Specification |
|---|---|
| Matched model | 5HHL-35 |
| Structure | Batch circulating |
| Drying method | Indirect heating |
| Drying technology | Mixed flow |
| Batch capacity | 35 t |
| Moisture reduction rate | 0.6–1.5%/h (English sheet) / 0.7–1.4%/h (new product material) |
| Hot air temperature | 40–60°C (English sheet) / 45–55°C (new product material) |
| Number of drying sections | 1 |
| Drying section height | 4000 mm |
| Number of tempering sections | 1 |
| Tempering section height | 1700 mm |
| Effective volume | 62.53 m³ |
| Hot air supply | Positive pressure |
| Hot air fans | 6 × GKF/G6S-2 high-temperature axial-flow drying fans |
| Motor power per fan | 3 kW |
| Total motor power of dryer | 25.1 kW |
| Total matched power | 32.45 kW |
| Heat source | Biomass pellet |
| Matched furnace | 5L-45 biomass pellet furnace |
| Heat output | 1.9×10⁶ kJ/h |
| Elevator capacity | 35 t/h |
| Grain cycle period | About 90 minutes |
| Loading time | About 60 minutes |
| Discharge time | About 75 minutes |
| Dryer dimensions | 4855×7250×11050 mm (English) / 7065×4700×10950 mm (Chinese) |
| Furnace dimensions | 2500×1450×4300 mm |
| Suggested eave height | 12.5 m |
Product Advantages
Why the 35-ton model is one of the strongest newly developed dryer pages for publication.
Best-documented new-generation model
The current source set provides the most complete parameter expansion for the 5HHL-35.
Low-temperature grain-quality focus
Low-temperature hot air, angle-box drying structure, and mixed-flow logic help reduce grain fissure risk and support quality protection.
Compact and automated
The page combines compact house-type structure with PLC-integrated one-touch control for loading, drying, ventilation, and discharge.
Key Features
Core engineering features highlighted by the current source materials.
Double-Sided Mixed-Flow Drying
Mixed-flow drying helps improve heat distribution and practical moisture removal efficiency.
Indirect Low-Temperature Heating
Indirect heating and low-temperature hot air help protect grain quality during drying.
PLC-Integrated Control
PLC-integrated control supports one-touch operation across major process stages.
Compact House-Type Structure
The source materials emphasize compact installation and relatively low civil-investment demand.
Flexible Heat-Source Matching
Can be matched with biomass pellet furnace, coal furnace, natural gas burner, or heat pump at series level.
Broad Grain Suitability
Suitable for paddy, wheat, corn, rapeseed, sorghum, and soybean.
Applications
Typical use cases for the 5HHL-35.
Paddy Drying
Suitable for paddy-drying projects that require practical grain-quality protection.
Seed Drying
A good fit for customers who want gentler drying for seed-related work.
Farm and Collection Projects
Useful for practical batch drying in farm, collection-point, and small commercial settings.
Flexible Heat-Source Projects
Works well where customers want to match different furnace or burner options.
