Technical Specifications
Expanded and source-backed technical fields for the 5HHL-55.
| Parameter | Specification |
|---|---|
| Matched model | 5HHL-55 |
| Structure | Batch circulating |
| Drying method | Indirect heating |
| Drying technology | Mixed flow |
| Batch capacity | 55 t |
| Moisture reduction rate | 0.6–1.5%/h (English sheet) / 0.7–1.4%/h (new product material) |
| Hot air temperature | 40–60°C (English sheet) / 45–55°C (new product material) |
| Number of drying sections | 1 |
| Drying section height | 5000 mm |
| Number of tempering sections | 1 |
| Tempering section height | 2500 mm |
| Effective volume | 99.4 m³ |
| Hot air supply | Positive pressure |
| Hot air fans | 6 × GKF/G6S-2 high-temperature axial-flow drying fans |
| Motor power per fan | 3 kW |
| Total motor power of dryer | 25.1 kW |
| Total matched power | 35.5 kW |
| Heat source | Biomass pellet |
| Matched furnace | 5L-80 biomass pellet furnace |
| Heat output | 3.36×10⁶ kJ/h |
| Elevator capacity | 35 t/h |
| Grain cycle period | About 130 minutes |
| Loading time | About 100 minutes |
| Discharge time | About 110 minutes |
| Dryer dimensions | 4855×7250×12850 mm (English) / 7250×4855×12900 mm (Chinese) |
| Furnace dimensions | 3600×1500×4600 mm |
| Suggested eave height | 14.5 m |
Product Advantages
Why the 55-ton model is the larger retained new-generation dryer.
Larger capacity with compact logic
The 55-ton model offers larger batch capacity while still emphasizing compact installation compared with many traditional layouts.
Low-temperature quality protection
Low-temperature drying supports paddy and wheat quality while keeping throughput at a practical commercial level.
Practical matched-furnace pairing
The current source set directly pairs this dryer with the 5L-80 biomass pellet furnace.
Key Features
Core engineering features highlighted by the current source materials.
Double-Sided Mixed-Flow Drying
Mixed-flow drying supports practical moisture removal and larger-batch airflow organization.
Indirect Low-Temperature Heating
Indirect heating helps support cleaner hot air and practical grain-quality protection.
PLC-Integrated Control
The new-generation family emphasizes integrated control across loading, drying, ventilation, and discharge.
Compact Installation Strategy
Retained as a new-generation model for customers needing larger capacity without excessive installation sprawl.
Flexible Heat-Source Matching
Series-level materials support biomass pellet furnace, coal furnace, natural gas burner, or heat pump matching.
Broad Grain Suitability
Suitable for paddy, wheat, corn, rapeseed, sorghum, and soybean.
Applications
Typical use cases for the 5HHL-55.
Medium-to-Large Batch Drying
Suitable for customers who need more capacity than entry-level batch dryers.
Rice Mills and Processing Projects
Works well for grain processing users requiring larger-capacity batch drying.
Paddy and Wheat Drying
A practical fit for paddy and wheat projects where grain quality remains important.
Matched-Furnace Projects
Useful where users want an integrated furnace-plus-dryer matching solution.
Need a 55-Ton Batch Dryer for Your Project?
Contact Tongtai Group for project matching, heat-source planning, and technical support for the 5HHL-55 batch dryer.
