Technical Specifications
Verified medium-capacity furnace data from the current workbook-based source set.
| Parameter | Specification |
|---|---|
| Model | 5SL-150 Rice Husk Furnace |
| Heat capacity | 1.5 million KCAL/h |
| Dimensions | 5900 × 6400 × 8520 mm |
| Fuel consumption | 220–550 kg/h |
| Ash discharge | 40–95 kg/h |
| Total power | 18.63 kW |
| Matched dryers | 5HHL-32 ×4 |
| Weight | 18300 kg |
| Combustion mode | Suspended combustion |
| Heating method | Indirect heating / indirect heat exchange |
| Thermal efficiency | ≥80% |
| Rated voltage | 220V/380V 50Hz |
| Fuel suitability | Rice husk, chaff, sawdust and similar renewable fuels |
Product Advantages
Why the 5SL-150 is a practical mid-range husk furnace for grain drying lines.
Higher medium-range heat output
The 5SL-150 provides more heat capacity than compact furnace models while keeping the same renewable-fuel operating logic.
Indirect heating for grain drying
Indirect heating makes it suitable for grain-dryer applications that require cleaner hot-air delivery.
Multi-dryer matching
The workbook positions this model for matching with 5HHL-32 ×4, making it useful for multi-dryer layouts.
Key Features
Core confirmed features of the 5SL-150 model and its series logic.
Suspended Combustion
Suspended combustion is a confirmed operating principle in the source workbook.
Indirect Heat Exchange
Indirect heat exchange supports clean hot-air output for drying applications.
Renewable Husk Fuel
Suitable for rice husk, chaff, sawdust and similar renewable-fuel operation.
Automatic Feeding & Handling
The series materials describe automatic feeding and ash-discharge logic.
Alarm Functions
Alarm and operating-status logic are included in the workbook-based description.
Matched Dryer Installation
Built for matched grain-dryer installations requiring more heat than entry models.
Applications
Typical scenarios where the 5SL-150 is a good fit.
Batch Grain Dryers
Suitable for matched batch-dryer configurations and practical drying-line support.
Paddy and Grain Drying
Works well for paddy and other grain drying applications that need renewable-fuel heating.
Compact Drying Lines
Useful for compact drying lines that need more heat output without moving to very large furnace classes.
Multi-Dryer Matching
Positioned for projects that need stable hot air across several matched dryers.
