Technical Specifications
Corrected worksheet-based parameters for the 5SL-200 model.
| Parameter | Specification |
|---|---|
| Model | 5SL-200 Rice Husk Furnace |
| Heat capacity | 2 million KCAL/h |
| Dimensions | 6790 × 6650 × 9250 mm |
| Fuel consumption | 260–660 kg/h |
| Ash discharge | 40–110 kg/h |
| Total power | 22.13 kW |
| Matched dryers | 5HHL-32 ×6 |
| Combustion mode | Suspended combustion |
| Heating method | Indirect heating / indirect heat exchange |
| Thermal efficiency | ≥80% |
| Rated voltage | 220V/380V 50Hz |
| Fuel suitability | Rice husk, chaff, sawdust and similar renewable fuels |
Product Advantages
Why the 5SL-200 is a practical high-capacity husk furnace.
High-capacity renewable-fuel heating
The 5SL-200 gives grain drying systems a stronger renewable-fuel heat source without moving to the very largest furnace class.
Stable indirect hot air
Its documented indirect-heating structure supports practical grain-dryer matching and cleaner hot-air delivery.
Workbook-matched configuration
This model is matched in the workbook with 5HHL-32 ×6, which supports stronger line-level drying layouts.
Key Features
Core confirmed features based on the approved website master materials.
Suspended Combustion
Designed for suspended combustion and practical renewable-fuel operation.
Indirect Heat Exchange
Indirect heat exchange supports stable hot-air supply for grain drying.
Husk-Based Fuel Use
Suitable for rice husk, chaff, sawdust and similar renewable fuels.
Handling Automation
Series-level materials confirm automatic feeding and ash-discharge logic.
Alarm Support
Alarm functions are included in the 5SL-series source description.
Line Matching
Appropriate for larger matched dryer installations requiring more heat output.
Applications
Typical application scenarios for the 5SL-200.
Commercial Grain Drying
Suitable for commercial grain drying systems that need stronger heat output.
Paddy and Grain Dryers
Practical for paddy and grain dryers using renewable husk fuel.
Multi-Dryer Projects
Useful for matched multi-dryer configurations with higher heat demand.
Integrated Drying Lines
Fits drying lines that need renewable fuel and stable indirect heating.
Need a Rice Husk Furnace for Your Project?
Contact Tongtai Group for rice husk furnace matching, heat-source planning, and project-oriented support for grain drying systems.
